PL-CV | LED POWER SUPPLY

LDN-CV1215PL,LDN-CV2415PL

BASIC INFORMATION:
Constant voltage 15W DC12V, 24V, indoor slim line type LED power supply
Driver Type: Constant voltage IC
Housing material: PC(V0)
Installation: Terminal block
Application: LED cabinet light, LED strip light, etc.

Safety standard:
EN613471,EN61347-2-13
EMI: EN55015
EMS: EN6 1000-3-2.: EN61000-3-3; EN61547
EMF: EN62493-2010
ERP: EN1194-2012

TECHNICAL CHARACTERISTICS

Code	Power	Input	Output	λ	(LWH/mm)	IP Grade	Dim
15W CV 12/24V Line type LED Power supply
LDN-CV1215PL	15W	220-240V	DC12V,1.25A Max	≥87%	1603016	IP20	Non-dim
LDN-CV2415PL	15W	220-240V	DC24V,0.625A Max	≥87%	1603016	IP20	Non-dim

Code	Power	Input	Output	λ	(LWH/mm)	IP Grade	Dim
30W CV 12/24V Line type LED Power supply
LDN-CV1230PL	30W	220-240V	DC12V,2.5A Max	≥85%	2513016	IP20	Non-dim
LDN-CV2430PL	30W	220-240V	DC24V,1.25A Max	≥85%	2513016	IP20	Non-dim

Code	Power	Input	Output	λ	(LWH/mm)	IP Grade	Dim
45W CV 12/24V Line type LED Power supply
LDN-CV1245PL	45W	220-240V	DC12V,3.75A Max	≥85%	2513016	IP20	Non-dim
LDN-CV2445PL	45W	220-240V	DC24V,1.87A Max	≥85%	2513016	IP20	Non-dim

Code	Power	Input	Output	λ	(LWH/mm)	IP Grade	Dim
60W CV 12/24V Line type LED Power supply
LDN-CV1260PL	60W	220-240V	DC12V,5.0A Max	≥85%	3053017	IP20	Non-dim
LDN-CV2460PL	60W	220-240V	DC24V,2.5A Max	≥85%	3053017	IP20	Non-dim

Code	Power	Input	Output	λ	(LWH/mm)	IP Grade	Dim
75W CV 12/24V Line type LED Power supply
LDN-CV1275PL	75W	220-240V	DC12V,6.25A Max	≥85%	3053017	IP20	Non-dim
LDN-CV2475PL	75W	220-240V	DC24V,3.12A Max	≥85%	3053017	IP20	Non-dim

Code	Power	Input	Output	λ	(LWH/mm)	IP Grade	Dim
100W CV 12/24V Line type LED Power supply
LDN-CV12100PL	100W	220-240V	DC12V,8.33A Max	≥85%	3203019	IP20	Non-dim
LDN-CV24100PL	100W	220-240V	DC24V,4.17A Max	≥85%	3203019	IP20	Non-dim

Code	Power	Input	Output	λ	(LWH/mm)	IP Grade	Dim
150W CV 12/24V Line type LED Power supply
LDN-CV12150PL	150W	220-240V	DC12V,12.5A Max	≥85%	3603124	IP20	Non-dim
LDN-CV24150PL	150W	220-240V	DC24V,6.25A Max	≥85%	3603124	IP20	Non-dim
