Full light 18W 24W | LED CEILING LIGHT

BASIC INFORMATION:
Back light LED Ceiling light TUYA CCT change dimmable 3 in 1 18W 24W
Installation: Screw-in
Connection: Terminal block inside
LED board: Aluminium
LED: SMD2835
Driver: Constant current IC
Housing: PMMA LGP, ABS+PP housing, PET Diffuser
Application: Home, hotels, office,etc.
Certificate: TUV

Special Options:
1. TUYA control
2. TRIAC Dim
3. 3-Step light dim
3. CCT changable by button
4. CCT changable by Switch

eel E grade 180x180

TECHNICAL CHARACTERISTICS

EMC Directive 2014/30/EU(EMC)：
EN 55015: 2013
EN 61547: 2009
EN 61000-3-2:2014
EN 61000-3-3:2013
Safety Directive 2014/35/EU(LVD)：
EN 62560: 2012
EN 62471: 2008
EN 62473 :2015
ERP Directive: (EU) 2019/2020
EEL (EU) 2019/2015

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	Control Mode
FULL LIGHT 18W LED CEILING LIGHT
LUCL-S18M-R300	85-265V	18 W	0.5	1450lm	81	3000K	Normal
LUCL-S18M-R300	85-265V	18 W	0.5	1450lm	81	4000K	Normal
LUCL-S18M-R300	85-265V	18 W	0.5	1450lm	81	6500K	Normal

Code	Input	Power	PF	Lumen	C.R.I	C.C.T.	Control Mode
FULL LIGHT 24W LED CEILING LIGHT
LUCL-S24M-R420	85-265V	24 W	0.5	2000lm	81	3000K	Normal
LUCL-S24M-R420	85-265V	24 W	0.5	2000lm	81	4000K	Normal
LUCL-S24M-R420	85-265V	24 W	0.5	2000lm	81	6500K	Normal
